CURT 13455 Class 3 Trailer Hitch; 2-Inch Receiver; Fits Select Land Rover Discovery
Whatever your task at hand -- whether its launching that boat before daybreak, setting up your camper before the rush or getting a final load to the dump before close -- CURT class 3 trailer hitches offer the strength needed for serious towing. They make it easy to hitch up and Bring It, offering a vehicle-specific fit and the weight capacity to handle a variety of trailers. Custom class 3 hitches are the most common type of receiver hitch for pickup trucks and SUVs. Because of their weight range, they are also found on full-size cars, crossovers and minivans. Each custom-fit class 3 hitch package is made for vehicle-specific mounting. This particular kit fits certain years of the Land Rover Discovery (see application info to verify vehicle compatibility). It provides a weight carrying capacity of 5,000 lbs. GTW and 500 lbs. TW. It is also compatible with a weight distribution hitch for level towing and a rating of 5,500 lbs. WD and 550 lbs. WDTW. CURT class 3 trailer hitches are typically used to attach and haul utility trailers, boat trailers, campers, snowmobile or ATV haulers and more (NOTE: Never exceed the lowest-rated towing component). Each class 3 hitch has a 2 in. receiver tube and is tested in accordance with SAE J684 for safety. To ensure that CURT class 3 receiver hitches have what it takes for serious trailering, they are designed using a hands-on approach and are constructed with rugged, high-strength steel and precise welding. We also protect our class 3 hitches in a co-cured finish of liquid A-coat and black powder coat for superior resistance to rust, chipping and UV damage.
- Made w/A Vehicle-Specific Design For A Custom Fit
- Tested For Safety In Accordance w/SAE J684
- Precisely Welded For Superior Strength And Fit
- Protected By A Durable High-Gloss Black Powder Coat Finish
- Co-Cured In A Rust-Resistant Liquid Bonderite Coating
- Strengthened w/A Cast Welded Seamless Collar
- Equipped w/An Open-Back Receiver For Easy Cleaning
- Backed By A Limited Lifetime Warranty
- Made in USA [may include imported hardware]
Information:
Class 3 Trailer Hitch, 2 Receiver, Select Land Rover Discovery; Rated to 5,000 lbs. gross trailer weight and 500 lbs. tongue weight; Compatible with weight distribution hitch (5,500 lbs. WD / 550 lbs. WDTW); Engineered with a vehicle-specific design for a custom fit; Tested for safety in accordance with SAE J684; Precisely welded for superior strength and fit; Protected by a durable high-gloss black powder coat finish; Co-cured in a rust-resistant liquid A-coat, inside and out; Equipped with an open-back receiver for easy cleaning; Limited lifetime warranty (one-year finish, one-year parts); Made in USA (may include imported hardware)
Application Summary:
| Year |
Make/Model |
| 1999-2002 |
Land Rover Discovery |
| Attributes |
| Body Shape |
Flat |
| Box Height in Inches - XA |
16 |
| Box Length in Inches - XA |
13 |
| Box Width in Inches - XA |
13 |
| California Proposition 65 |
Yes |
| Class ID |
3 |
| Container Volume Cubic Feet - XA |
0.00000 |
| Container Volume Cubic Meter - XA |
0.00000 |
| Country of Origin (Primary) |
US |
| Drilling Required |
No |
| Emission Code |
Legal US |
| Finish |
Gloss Black Powder Coat |
| Finish - XA |
GLOSS BLACK POWDER COAT |
| Gross Trailer Weight |
5000 lbs. |
| Gross Trailer Weight (lbs.) |
5000 |
| Harmonized Tariff Code (Schedule B) |
8708998180 |
| Hazardous Material Code |
N |
| Install Time |
30 Minutes |
| Item Class - XA |
MFH |
| Item Height - XA |
6.780 |
| Item Length - XA |
16.010 |
| Item Width - XA |
11.540 |
| Life Cycle Status Code |
Available Only While Supplies Last |
| Long Description |
Class III Trailer Hitch |
| Main Body Shape |
Flat |
| Master Case Height Inches - XA |
0.000 |
| Master Case Length Inches - XA |
0.000 |
| Master Case Volume Cubic Feet - XA |
0.00000 |
| Master Case Weight Lbs - XA |
0.000 |
| Master Case Width Inches - XA |
0.000 |
| Material - XA |
Carbon Steel |
| Mount Type Description - XA |
Blank |
| NAFTA Preference Criterion Code |
B |
| Pallet Total Height Inches - XA |
0.000 |
| Pallet Total Weight Per - XA |
0.000 |
| Parcel Allowed - XA |
Yes |
| Position |
Rear |
| Price Code - XA |
88 |
| Product Weight - XA |
22.000 |
| Rate Class - XA |
70.0, 125.0 |
| Receiver Tube Size |
2 IN, 2.000 in. |
| Retail Height - XA |
14.000 |
| Retail Length - XA |
17.000 |
| Retail Width - XA |
14.000 |
| Sales Family Code - XA |
HITCH |
| Sales Family Description - XA |
HITCH |
| Sales Group Description - XA |
CL 3 |
| SDR Required Flag |
N |
| Shipping Weight - XA |
24.000 |
| Side Application Type Description - XA |
Blank |
| Tariff 301 - XA |
No |
| Tongue Weight (TW) |
500 LB |
| Tongue Weight(TW) |
500 LB |
| Truckload Volume Cubic Feet - XA |
0.00000 |
| Visibility |
Exposed |
| Warranty |
Limited Lifetime Warranty (One-Year Finish, One-Year Parts) |
| WC Tongue Weight |
500 |
| WD Tongue Weight |
550 |
| Weight Carrying Capacity |
5000 |
| Weight Carrying Capacity (WC) |
5,000 LB |
| Weight Carrying Capacity(WC) |
5,000 LB |
| Weight Distribution |
5500 |
| Weight Distribution (WD) |
5,500 LB |
| Weight Distribution Tongue Weight (WDTW) |
550 LB |
| Weight Distribution Tongue Weight(WDTW) |
550 LB |
| Weight Distribution(WD) |
5,500 LB |
| GTIN |
00612314834556 |
